Nedo Builders’ Levels X-Series
Nedo X-levels are top-quality builders’ levels which meet the very highest demands. These builders’ levels feature particularly bright optics, a large objective aperture, a sturdy air-damped compensator and quality workmanship – just right for use under eXtremely tough conditions.
Features:
- Automatic builders’ level with 24x and 32x magnification
- Bright optics with large objective aperture
- Rugged metal housing
- Sturdy, reliable air-damped compensator
- High-contrast image
- Inspection record
- Comes with plumb bob, adjusting pin and robust case
- Also available as a set
Nedo Builders’ Levels X-Series
| Type | X24 | X32 |
| Image | upright | upright |
| Magnification | 24x | 32x |
| Clear objective aperture | 40 mm | 40 mm |
| Shortest focusing distance | 0.6 m | 0.6 m |
| Multiplication factor | 100 | 100 |
| Compensator operating range | ± 15’ | ± 15’ |
| Setting accuracy | ± 0.5’’ | ± 0.3’’ |
| Horizontal circle | 400 gon | 400 gon |
| Sensivity of circular bubble | 8’/2 mm | 8’/2 mm |
| Standard deviation per km double-run level | ± 2.0 mm | ± 1.0 mm |
| Protection class | IP 54 | IP 54 |
| Weigth | 1.6 kg | 1.6 kg |
| Connecting thread | 5/8’’ | 5/8’’ |
| Ref.-No. | 460759 | 460760 |
| Ref.-No. Set | 464245 | 464325 |
